| User Capacity |
5300 |
| Face User |
300 |
| Card/PIN User |
5000 |
| PIN Length |
4~6 digits |
| Operating Voltage |
12~18V DC |
| Idle Current |
≤80mA |
| Active Current |
≤250mA |
| Proximity Card Reader |
EM+Mifare |
| Radio Technlogy |
125KHz/13.56MHz |
| Read Range |
1~3cm |
| Wiring Connections |
Relay output,exit button,alarm,door contact,Wiegand input/output |
| Relay |
One(NO,NC,Common) |
| Adjustable Relay Output Time |
0~99 Seconds(5 seconds default) |
| Lock Output Load |
2 Amp Maximum |
| Wiegand Interface |
EM card：Wiegand 26~44 bits input & output(Factory default: Wiegand 26bits) |
| Mifare card：Wiegand 26~44 bits,56bits,58bits input & output(Factory default: Wiegand 34bits) |
| PIN Output |
4 bits,8bits (ASCII),10 digits Virtual Number(Factory default:4bits) |
| Environment |
IP66 |
| Operating Temperature |
-20℃ ~ 60℃ |
| Operating Humidity |
0%RH ~ 98%RH |
| Physical |
Zinc-Alloy |
| Color |
Sliver & Black |
| Dimensions |
L140*W68*H25(mm) |
| Unit Weight |
500g |
| Shipping Weight |
615g |
